CTEK NXT 15 NA

Introducing the NXT 15 battery charger. It’s a powerful, high-performance 15A charger, packed with award-winning Swedish technology – and with CTEK’s DNA running through it. NXT 15 ensures flawless charging and maintenance for 12V lead acid and lithium-ion batteries. Features include desulphation modes, reconditioning for deeply discharged batteries, constant 13.6V supply mode, and built-in temperature sensor for optimal charging in any weather. It’s fully automatic so just ‘connect-and-forget’– safe, spark-free and perfect for performance vehicles, boats, caravans, trucks and more.

Features

• 15 A power for faster charging and consistent performance.
• Supports 12V lead acid & lithium* batteries (30-350Ah).
• Supply mode delivers constant power (13.6V/15A) to support the battery.
• Automatic temperature compensation for extreme weather.
• Fully automatic, spark-free and reverse polarity protected.
• Compact design with robust rubber cables.
• Patented desulphation & reconditioning modes restore battery life.
• Convenient ‘connect-and-forget’ usability.
• Backed by a 5-year manufacturer warranty for total peace of mind.
• Award-winning Swedish technology for unmatched performance.


Technical data

Charging category: AC charging

Input: 110–120 VAC, 50–60 Hz, 3.0 A

Output: 14.4/15.8/13.6 V, 15 A, lead-acid battery types. 13.8 V/14.4 V/13.3 V, 15 A, LiFePO₄

Battery chemistry: Lead acid; Lithium-ion

Battery types: 12 V:; WET; MF; Ca/Ca; AGM; EFB; GEL; LiFePO₄

Battery capacity: 30 Ah - 350 Ah

Back current drain*: corresponding to less than 1Ah/month

Battery voltage: 12V

Ambient operating temperature: -4 °F to +122 °F (-20 ˚C to +50 ˚C)

Cooling: Fan

Start voltage: 2.0 V

Ripple**: Less than 4%

Temperature compensation: External charge voltage temperature compensation sensor.

Degree of protection: IP44

Dimensions: (L x W x H) 9.25 x 5.12 x 2.56 in

Disclaimer: All products and product specifications are subject to change without notice, to improve reliability, function or design. In the event of product error, we reserve the right to inspect the product and verify the fault. All product returns are subject to our standard warranty terms.

*) Back current drain is the current that drains the battery if the charger is not connected to the power outlet. CTEK chargers have a very low back current.

**) The quality of the charging voltage and charging current is very important. A high current ripple heats up the battery which has an aging effect on the positive electrode. High voltage ripple could harm other equipment that is connected to the battery. CTEK battery chargers produce very clean voltage and current with low ripple.

CTEK issues a limited warranty to the original purchaser of the product. Depending on the product, the limited warranty period will vary. The limited warranty is not transferable. The warranty applies to manufacturing faults and material defects. The warranty is void if the product has been handled carelessly or repaired by anyone other than CTEK or its authorized representatives. CTEK makes no warranty other than this limited warranty and is not liable for any other costs other than those mentioned above, i.e. no consequential damages. Moreover, CTEK is not obligated to any other warranty other than this warranty.
